CYT3004BM 兩級恒功率線性LED恒流控制芯片

The CYT3004BM is a dual-channel progressive LEDlinear constant current control chip which usesconstant current control technology to precisely setthe LED current through external resistors.It integrat...
  • CYT3004BM
  • 品 牌:CYT
  • 參考價:1.5    庫 存:99999+
  • 數(shù) 量:
  • 產(chǎn)品描述:

    The CYT3004BM is a dual-channel progressive LEDlinear constant current control chip which usesconstant current control technology to precisely setthe LED current through external resistors.It integrates the input line network voltagecompensation function, which can maintain constantinput power by adjusting the output currentmagnitude through an external resistor within therated input voltage range.It has over temperature adjustment function toimprove the reliability of system. The system structureis simple, with few peripheral components and lowsolution cost.

    Few peripheral components, low solution cost

    Constant current control technology

    OUT port current is up to 65mA

    Output current error between chip and chip: < ±5%

    Input voltage: 220Vac

    Dual-channel progressive constant current method

    Accommodates a wide input voltage range of ±20%

    Input line network voltage compensation

    Over-temperature adjustment function

    Chip can share PCB board with LED

    Package: ESOP8
